BEP Marine BEP 500A Pro Installer Heavy Duty Bus Bar 4-Stud

Reliable electrical installation

The BEP 500A Pro Installer Heavy Duty Bus Bar features compact footprints and modular design that allows for space saving and scalability. Robust construction, thicker copper conductors and additional mounting holes provide the basis for secure, reliable, electrical installation.

The cover features a snap-out side skirt providing additional cable entry as required, while the label recess provides the perfect landing for handheld-printer labels. It’s easy linking to other Pro Installer products because of the common interconnection height, and the radiused bus bar ends improve cable routing options for large cables.

Long, threaded studs to connect up to four large cable lugs. Tinned CDA102 Copper conductors, stainless steel studs/screws, and nickel-plated brass nuts provide longevity in the marine environment and prevent thread galling during tightening.

BEP 500A Pro Installer Heavy Duty Bus Bar Features:

• Studs: Four
• Stud Diameter: 8mm
• DC Rating: 500A
• Dimensions: 3 7/8″ x 1 7/8″ x 2 3/8″

BEP 500A Pro Installer Heavy Duty Bus Bar Specifications:

• Capacity: DC: 500 Amps
• Dimensions (W x H x L): 1 7/8″ x 2 3/8″ x 3 7/8″
• Mounting Hardware: Screw Fasteners (Sold Separately)
• Type: Bus Bars
• Warranty: Five Years
