BEP Marine BEP Switchable Reset 120A Panel Mount

The BEP Switchable Reset 120A Panel Mount is among
the heavy-duty single pole thermal type breakers from Marinco that
are ideal for auxiliary and accessory circuits, trucks, buses, RVs
and marine applications, battery chargers and DC audio systems.
Series 184 and 185 are sealed for engine compartment and bilge area
applications. Stud insulators are provided on covered units with F
(Surface Mount) bases; tin plated copper studs, brass rivets and
stainless steel locking nuts.

BEP Switchable Reset 120A Panel Mount
Specifications:

• Ratings: 30-150A; 30V DC, 3000A interrupt capacity
• Operating Temperature: -25 deg F (-32 deg C) to 180 deg F (82
  deg C)
• Storage Temperature: -30 deg F (-34 deg C) to 300 deg F (149
  deg C)
• Housing: Thermoset plastic; UL rated 94VO; 311 deg F (155 deg
  C)
• Mounting: Panel
• Terminal Stud Torque: 50 in-lb (5.6Nm) max
• Indicator: Series 184 & 185 have a unique reset mechanism
  providing visible indication of tripped condition
• Ingress Protection Rating: IP67
• Approvals: Complies with SAEJ1625, J1171 and UL1500 (Ignition
  protected) specifications
